| Overall length (without 3p) | 3200 mm | ||
|---|---|---|---|
| Overall width | 1495 mm | ||
| Overall height (Top of canopy) | 2049 mm | ||
| Wheel Base | 1925 mm | ||
| Min. ground clearance | 400 mm (15.7 in.) | ||
| Tread | Front | 1150 mm | |
| Rear | 1155, 1225 mm | ||
| Weight | 1493 kg | ||
| Drive System | 4WD |
| Model | V2403-M-DI |
| Type | Direct injection, Vertical, Water-Cooled, 4-cycle diesel |
| Number of cylinders | 4 |
| Bore and stroke | 87 × 102.4 mm |
| Total displacement | 2.434 L |
| Engine gross power* | 38.0(51.0 / 51.7) kW (HP/PS) |
| Engine net power* | 36.2(48.5 / 49.2) kW (HP/PS) |
| Power Drive Shaft (PTO Shaft)* | 31.7(42.6 / 43.1) kW (HP/PS) |
| Rated revolution | 2700 rpm |
| Maximum torque | 164 N-m |
| Battery | 75D26R, 12V 52Ah, RC: 98 min, CCA(-18[image]): 450 A |
| Fuel | Diesel (Supports B7, B10 and B20 Diesel Fuel) |
| Fuel tank | 48 L |
| Engine crankcase (with filter) | 7.6 L |
| Engine coolant | 7 L |
| Transmission case | 40 L |
| Standard tire size | Front | 8-18 |
|---|---|---|
| Rear | 13.6-26 | |
| Clutch | Dry type single stage | |
| Steering | Hydrostatic power steering | |
| Transmission | Gear shift, 8 forward and 8 reverse | |
| Brake | Mechanical, Wet disk type | |
| Min. turning radius (with brake) | 2.65 m | |
| Hydraulic control system | Position control |
| Pump capacity | 30.5 L / min |
| System pressure | 17.7(180) (kgf / cm) |
| 3-point hitch | Category 1 |
| Max. lift force At lift points | 1300 kg |
| Max. lift force 24 in. (610 mm) behind lift points | 1053 kg |
| Rear PTO | SAE 1-3/8, 6 splines |
|---|---|
| PTO /Engine speed | 540/2268, 750/2348 (rpm) |
| Overall length (without 3p) | 3200 mm | ||
|---|---|---|---|
| Overall width | 1495 mm | ||
| Overall height (Top of canopy) | 2049 mm | ||
| Wheel Base | 1925 mm | ||
| Min. ground clearance | 400 mm (15.7 in.) | ||
| Tread | Front | 1150 mm | |
| Rear | 1155, 1225 mm | ||
| Weight | 1493 kg | ||
| Overall length (without 3p) | 3200 mm | ||
|---|---|---|---|
| Overall width | 1495 mm | ||
| Overall height (Top of canopy) | 2049 mm | ||
| Wheel Base | 1925 mm | ||
| Min. ground clearance | 400 mm (15.7 in.) | ||
| Tread | Front | 1150 mm | |
| Rear | 1155, 1225 mm | ||
| Weight | 1493 kg | ||
| Overall length (without 3p) | 3200 mm | ||
|---|---|---|---|
| Overall width | 1495 mm | ||
| Overall height (Top of canopy) | 2049 mm | ||
| Wheel Base | 1925 mm | ||
| Min. ground clearance | 400 mm (15.7 in.) | ||
| Tread | Front | 1150 mm | |
| Rear | 1155, 1225 mm | ||
| Weight | 1493 kg | ||
