| Overall Length | 3,760mm |
|---|---|
| Overall Width (minimum tread) | 2,010mm |
| Overall Height | 2,535mm (Muffler) |
| Wheel Base | 2,250 (95.9 in.) |
| Tread | Front: 1,660mm |
| Rear: 1,540mm to 1,940mm | |
| Minimum Ground Clearance | 450mm (Drawbar Jacket) |
| Weight | 2,710 kg |
| Model | V3800-DI-T |
|---|---|
| Type | Direct Injection, liquid cooled 4 cylinder diesel |
| No. of Cylinders | 4 |
| Power | 70.8 kW (95 HP) |
| Battery Capacity | 12 V |
| Fuel Tank Capacity | 90 L |
| Standard Tire Size | Front: 12.4-24 |
|---|---|
| Rear: 18.4-30 | |
| Clutch | Dry single plate |
| Steering | Hydraulic power steering |
| Braking system | Hydraulic wet discs |
| Differential | Bevel gears with different lock (Rear) |
| Hydraulic control system | Position, draft (top link sensing) and mix control |
|---|---|
| Pump Capacity | 69.3 L/min |
| Three Point Hitch | Category 2 |
| Remote Hydraulic Control | One remote valve |
| Traction System | Swinging drawbar, adjustable in direction |
| Direction of Turning | Clockwise, viewed from tractor rear |
|---|---|
| PTO Engine Speed | 6 spline: 540/2205 |
| Overall Length | 3,760mm |
|---|---|
| Overall Width (minimum tread) | 2,010mm |
| Overall Height | 2,535mm (Muffler) |
| Wheel Base | 2,250 (95.9 in.) |
| Tread | Front: 1,660mm |
| Rear: 1,540mm to 1,940mm | |
| Minimum Ground Clearance | 450mm (Drawbar Jacket) |
| Weight | 2,710 kg |
| Overall Length | 3,760mm |
|---|---|
| Overall Width (minimum tread) | 2,010mm |
| Overall Height | 2,535mm (Muffler) |
| Wheel Base | 2,250 (95.9 in.) |
| Tread | Front: 1,660mm |
| Rear: 1,540mm to 1,940mm | |
| Minimum Ground Clearance | 450mm (Drawbar Jacket) |
| Weight | 2,710 kg |
| Overall Length | 3,760mm |
|---|---|
| Overall Width (minimum tread) | 2,010mm |
| Overall Height | 2,535mm (Muffler) |
| Wheel Base | 2,250 (95.9 in.) |
| Tread | Front: 1,660mm |
| Rear: 1,540mm to 1,940mm | |
| Minimum Ground Clearance | 450mm (Drawbar Jacket) |
| Weight | 2,710 kg |
