Kubota Philippines, Inc.

ZT100

ZT 100

Product Specifications

Dimension
Model ZT100(TVS)
Type Four-stroke water cooled horizontal diesel engine
Bore x Stroke mm(in) 88 x 90
Displacement Volume cc 547
Maximum Power kW/rpm 7.35/2400
hp/rpm 10/2400
Continuous Rated Output rpm 9/ 2400
kW/rpm 6.62kW/ 2400
Specific fuel Consumption at Continuous Rated Power g/PS-hi, g/kW-hi 269
Compression Ratio 22:01
Maximum Torque kg-m/rpm 3.5/1600
Coolant capacity cm3 (Liter) 2.1
Fuel Capacity cm3 (Liter) 10.5
Oil Capacity cm3 (Liter) 2.8
Fuel Type Automotive used diesel fuel (SAE No. 2-D
Lubricating oil grade SAE 40 API CF
Air Cleaning Type Oil both type
Combustion System Swril Pre- Combustion Chamber
Battery capacity (ES Model only) 12 Volt 30 A-h battery
Rotation direction of flywheel Turn counterclockwise when facing the flywheel
Net Weight (kg) 105
Gross Weight (kg) 120

Application Features

Efficiency
Model ZT100(TVS)
Type Four-stroke water cooled horizontal diesel engine
Bore x Stroke mm(in) 88 x 90
Displacement Volume cc 547
Maximum Power kW/rpm 7.35/2400
hp/rpm 10/2400
Continuous Rated Output rpm 9/ 2400
kW/rpm 6.62kW/ 2400
Specific fuel Consumption at Continuous Rated Power g/PS-hi, g/kW-hi 269
Compression Ratio 22:01
Maximum Torque kg-m/rpm 3.5/1600
Coolant capacity cm3 (Liter) 2.1
Fuel Capacity cm3 (Liter) 10.5
Oil Capacity cm3 (Liter) 2.8
Fuel Type Automotive used diesel fuel (SAE No. 2-D
Lubricating oil grade SAE 40 API CF
Air Cleaning Type Oil both type
Combustion System Swril Pre- Combustion Chamber
Battery capacity (ES Model only) 12 Volt 30 A-h battery
Rotation direction of flywheel Turn counterclockwise when facing the flywheel
Net Weight (kg) 105
Gross Weight (kg) 120
Durability
Model ZT100(TVS)
Type Four-stroke water cooled horizontal diesel engine
Bore x Stroke mm(in) 88 x 90
Displacement Volume cc 547
Maximum Power kW/rpm 7.35/2400
hp/rpm 10/2400
Continuous Rated Output rpm 9/ 2400
kW/rpm 6.62kW/ 2400
Specific fuel Consumption at Continuous Rated Power g/PS-hi, g/kW-hi 269
Compression Ratio 22:01
Maximum Torque kg-m/rpm 3.5/1600
Coolant capacity cm3 (Liter) 2.1
Fuel Capacity cm3 (Liter) 10.5
Oil Capacity cm3 (Liter) 2.8
Fuel Type Automotive used diesel fuel (SAE No. 2-D
Lubricating oil grade SAE 40 API CF
Air Cleaning Type Oil both type
Combustion System Swril Pre- Combustion Chamber
Battery capacity (ES Model only) 12 Volt 30 A-h battery
Rotation direction of flywheel Turn counterclockwise when facing the flywheel
Net Weight (kg) 105
Gross Weight (kg) 120
Convenience
Model ZT100(TVS)
Type Four-stroke water cooled horizontal diesel engine
Bore x Stroke mm(in) 88 x 90
Displacement Volume cc 547
Maximum Power kW/rpm 7.35/2400
hp/rpm 10/2400
Continuous Rated Output rpm 9/ 2400
kW/rpm 6.62kW/ 2400
Specific fuel Consumption at Continuous Rated Power g/PS-hi, g/kW-hi 269
Compression Ratio 22:01
Maximum Torque kg-m/rpm 3.5/1600
Coolant capacity cm3 (Liter) 2.1
Fuel Capacity cm3 (Liter) 10.5
Oil Capacity cm3 (Liter) 2.8
Fuel Type Automotive used diesel fuel (SAE No. 2-D
Lubricating oil grade SAE 40 API CF
Air Cleaning Type Oil both type
Combustion System Swril Pre- Combustion Chamber
Battery capacity (ES Model only) 12 Volt 30 A-h battery
Rotation direction of flywheel Turn counterclockwise when facing the flywheel
Net Weight (kg) 105
Gross Weight (kg) 120
